4950MHz-5550MHz Frequency Controlled Oscillator Within 3V-6V Voltage

Place of Origin : Jiangsu, China

Brand Name : RFint

Model Number : YSGMTC5200

Price : Prices are negotiable

Packaging Details : Opp bag

Delivery Time : 2-10days

Specification : Standard

Packaging Type : opp bag

Application : 4950MHz-5550MHz

Package / Case : Standard

Series : VCO

Features : High output power

Size / Dimension : 7mm*9mm*2mm

Description : Voltage Controlled Oscillator

Manufacturing Date Code : Other

Frequency : 4950~5550MHz

Output power : ≥ 6dBm @ VCC=5V

Supply voltage : 3V~6V

Working current : 14mA

Contact Now

INNOTION Original 8dBm VCO 4950MHz-5550MHz Voltage Controlled Oscillator for Integrated Circuits within 3V-6V Voltage
Product Description



YSGMTC5200 is a highly integrated, standard package size VCO, which uses a high cut-off frequency RF transistor to generate oscillation and signal output. Its signal output power is high and its isolation is good.

The temperature compensation device is added to improve the temperature stability of the signal. It is supplied by 5V standard voltage and is compatible with the working voltage in the range of 3V to 6V.
Characteristic parameter
Nominal tuning frequency band 4950~5550MHz@VT=0V ~ 5V
Output power  ≥6dBm @VCC=5V
In-band flatness (BW≤200MHz) ±0.5dB
Power supply voltage (VCC) 3V ~ 6V
Working current 14mA
Second harmonic suppression ≤-25dBc
Third harmonic suppression ≤-25dBc
Radio-frequency output impedance 50Ω
Universal package size  7mm x 9mm x 2mm
4950MHz-5550MHz Frequency Controlled Oscillator Within 3V-6V Voltage




4950MHz-5550MHz Frequency Controlled Oscillator Within 3V-6V Voltage

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super  WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2010,sell to Western Europe(50.00%),Southern Europe(12.00%).

2. how can we guarantee quality?
Always a pre-production sample before mass production;

Always final Inspection before shipment;

1 year warranty for our products.


3.what can you buy from us?
Signal Booster, VCO, Anti Drone Jammer Module, Power Amplifier, Gain Block and so on
